Product Overview

The XBD-W Series Horizontal Single-Stage Fire Pump is a horizontal single-stage centrifugal pump designed for fire protection water supply applications. The horizontal arrangement provides straightforward installation and maintenance access, making it suitable for a wide range of fire protection systems.

This fire pump delivers reliable fire protection water supply for fire hydrant systems, automatic sprinkler systems and water mist suppression systems. Depending on regional terminology, it may also be referred to as a Horizontal Single-Stage Fire Pump, End-Suction Fire Pump, Horizontal Single-Stage Fire Pump or XBD-WFire Pump.

Key Features

• Horizontal single-stage design for straightforward installation and maintenance access
• Reliable fire protection water supply for hydrant, sprinkler and water mist systems
• Robust structural design for extended service life in demanding fire protection applications
• Efficient hydraulic design for reduced energy consumption during fire pump operation
• Suitable for both fire protection and general water supply applications
• Wide range of sizes and configurations for diverse fire protection requirements

Applications

• Fire hydrant fire suppression systems in commercial and industrial buildings
• Automatic sprinkler fire protection systems
• Water mist fire suppression systems
• Fire protection water supply for residential buildings and office complexes
• Industrial facility fire protection including factories and warehouses
• Hospital and commercial building fire hydrant and sprinkler systems

Customer Benefits

Straightforward Installation and Maintenance

The horizontal single-stage design provides easy access to all pump components, simplifying installation procedures and reducing maintenance time and costs over the pump service life.

Reliable Fire System Readiness

The robust structural design and rational hydraulic configuration ensure dependable fire protection water supply during emergency events, maintaining system pressure and flow under demanding conditions.

Efficient Operation

The hydraulically optimised single-stage impeller design and efficient motor selection reduce power consumption during fire pump test runs and emergency operation, lowering operating costs.

Extended Service Life

Quality materials and robust construction reduce component wear and extend maintenance intervals, lowering total cost of ownership over the pump service life.

Versatile Application Range

In addition to fire protection duties, the XBD-W Series can serve general water supply applications, providing a versatile pumping solution for industrial and commercial installations.

Wide Configuration Options

A wide range of sizes and configurations enables the XBD-W Series to serve diverse fire protection requirements from small commercial installations to large industrial facilities.

Technical Specifications

Parameter	Specification
Product Series	XBD-W Series
Pump Type	Horizontal single-stage fire pump
Flow Rate	Customised per project requirements
Pressure	Customised per project requirements
Motor Power	Customised per project requirements
Installation Type	Horizontal

Selection Guidance

To select the appropriate XBD-W Series horizontal single-stage fire pump, please provide the following information:

• Required flow rate (L/s)
• Required pressure (MPa or bar)
• Fire protection system type (hydrant, sprinkler, water mist)
• Building type and occupancy classification
• Available installation space and pump room dimensions
• Available voltage and frequency
• Required duty point on the pump curve
• Applicable fire protection standards and codes

Final model selection should be confirmed according to the actual duty point, system requirements and applicable fire protection standards.

Installation and Maintenance

Installation Guidance

The pump should be installed on a rigid, level foundation with adequate clearance for inspection and maintenance access. The suction and discharge piping must be independently supported to prevent load transfer to the pump flanges.

Pre-Start Inspection

Before starting the pump, confirm the following:

• Pump is securely mounted and level
• Suction and discharge piping connections are complete and leak-free
• Pump casing is properly filled and primed
• Motor wiring is correct and terminals are secure
• Rotational direction matches the arrow indicated on the pump casing
• All fasteners are properly tightened

Routine Maintenance

Regular inspection should include:

• Checking mechanical seals for leakage
• Monitoring motor bearing temperature and vibration levels
• Verifying that the pump maintains the required flow and pressure during test runs
• Cleaning strainers and filters when necessary
• Inspecting all pipeline connections for signs of wear or leakage

Available Configurations

• Flow rates customised per project requirements
• Pressure range customised per project requirements
• Motor powers customised per project requirements
• Various pump sizes for different duty points
• Electric motor or diesel engine drive options
• Integrated control panels with automatic start and monitoring

FAQs

What is a horizontal single-stage fire pump?

It is a fire pump with a horizontal single-stage impeller design, providing straightforward installation and maintenance access for fire protection water supply applications.

What are the flow and pressure ratings?

Flow rate, pressure and motor power are determined according to specific customer requirements and project operating conditions.

What fire protection systems can this pump serve?

It is suitable for fire hydrant systems, automatic sprinkler systems and water mist fire suppression systems in residential, commercial, industrial and institutional buildings.

Why use a horizontal single-stage design?

The horizontal single-stage design provides easy access to all pump components, simplifying installation procedures and reducing maintenance time and costs.

Why use a fire pump instead of relying on mains pressure?

A dedicated fire pump ensures reliable fire protection water supply at the required flow and pressure during emergency events, independent of mains water pressure variations.

What maintenance is required?

Regular maintenance includes checking mechanical seals for leakage, monitoring motor bearing temperature and vibration, verifying flow and pressure during test runs, and inspecting pipeline connections.

Contact Chaodun

For product selection, technical data, performance information or project quotations, please contact Shanghai Chaodun Machinery Manufacturing Group Co., Ltd.

Website: https://chaodunpump.com

Email: Suzion@chaodunpump.com

WhatsApp: +44 751 8050 473
